Klein CURL Wired PTT Headset for XP5s and XP8

Klein CURL Wired PTT Headset for XP5s and XP8

$ 69.95 USD

The CURL Wired PTT Headset rests on the ear for comfortable, all-day use. The CURL headset may be worn on the right or left ear by simply rotating the earpiece. Klein custom designed the CURL headset to reliably connect to Sonim’s SecureAudio Connector on the XP5s and XP8 handsets. This allows the CURL headset connector to screw into the handsets. The CURL headset has a large, easy to access PTT button, compatible with heavy work gloves.

Push-to-Talk and full-duplex wired headset
Flexible C-ring earloop may be worn on right or left ear
Speaker rests on ear for comfortable, all day use
In-line noise reduction microphone
Easy to access and tactile PTT button
Built-in swivel clothing clip to easily attach headset cable to uniform
Omni-directional Microphone
Microphone Sensitivity -36dB±3dB
Microphone Impedance 2.2kΩ
Microphone Frequency Range 50-10KHz
Microphone Signal / Noise Ratio More than 58dB 1KHz 0dB=1V/Pa, A-Weight
Microphone Current Consumption Max: 0. 5μA RL=2.2KΩ Vs=3.0V(DC)
Microphone Operation Voltage Range 1.0-10V
Speaker Rated Power 500mW
Speaker Max Input Power 800mW
Speaker Impedance 16Ω±15%
Speaker Frequency Range F0-20KHz
Speaker Distortion Less than 2% at 2.0 kHz, 8.67vrms
Speaker Sensitivity 105dB±5%
Compatible with Sonim XP5s and XP8 handsets
Designed and Assembled in the USA
3 Year Limited Liability Warranty
Operating Temperature -40°C - +80°C
Klein CURL Length 46 inches, Weight 39g
Packaged Product Dimensions 5 x 6 x 1.5 inches, Weight 81g

Part No. CURL-SO3
UPC/EAN 854807007355
